    2-Ply Single Facer Corrugation Line, Single Faced Corrugated Cardboard Making Machine

    Ask Lasest Price
    Brand Name : Yush
    Model Number : DW-120
    Certification : CE
    Price : FOB: 15000~45000USD
    Payment Terms : T/T
    Supply Ability : 10 sets per month
    Delivery Time : 30~60 working days
    • Product Details
    • Company Profile

    2-Ply Single Facer Corrugation Line, Single Faced Corrugated Cardboard Making Machine

    DW-120 Single Facer Corrugation Line


    1) This product line consists of Hydraulic Shaftless Mill Roll Stand, Auto Splicer, Preheater, SF-320S Fingerless type Single Facer, NC Single Faced Slitter Cutter Stacker, Steam Boiler & Pipeline(customer-owned parts), etc.
    2) Kraft Paper Reel to corrugate and glue by Corn Starch Gum, continuously produce and cut to Single Faced Corrugated Cardboard Sheet, and then through Flute Laminator Machine or Sheet Pasting Machine to laminate to 3/5-ply corrugated sheet, press and fix.
    3) The production line has rational structure design, advanced producing flow, high efficiency, strong batch adjustability, easy operation, etc. Good work conditions.
    4) It is the ideal and perfect equipment for small or medium carton factories.


    Max Effective Width1100~2200mm
    Max Paper Roll Diameter1500mm
    Max Paper Roll Weight3000kg
    Corrugating RollerΦ320mm, 48CrMo alloy steel, hardness HRC58°-60°
    Cutting Length300~9999mm
    Cutting Precision±1mm
    Design Speed120m/min
    Heating MethodSteam Heating
    Economic Working Speed80~100m/min

    2-Ply Single Facer Corrugation Line, Single Faced Corrugated Cardboard Making Machine

    2-Ply Single Facer Corrugation Line, Single Faced Corrugated Cardboard Making Machine

    2-Ply Single Facer Corrugation Line, Single Faced Corrugated Cardboard Making Machine

    2-Ply Single Facer Corrugation Line, Single Faced Corrugated Cardboard Making Machine
