    Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

    Ask Lasest Price
    Brand Name : Yush
    Model Number : ZH-GQ
    Certification : CE
    Price : FOB: 40000~80000USD
    Payment Terms : T/T
    Supply Ability : 10 sets per month
    Delivery Time : 30~60 working days
    • Product Details
    • Company Profile

    Automatic Multi-function Folder Gluer Machine with Pre-fold & Bottom-lock, by glue guns, option for CD box

    ZH-GQ Automatic Folder Gluer with Pre-fold & Bottom-lock

    (by glue gun, optional for CD box)


    1. This machine is specially used for paperboard shaping and adhesive processing after cutting horizontally.
    2. Its universality is strong and suitable scope is wide, which can fold and paste various straight seaming box and bottom edging box.
    3. It is widely used in food, medicine, cosmetics, stationery and other ordinary cartons, process and glue for all kinds of bottom-locked cartons.
    4. Pre-fold section is applied to auto packaging, fold 1 and fold 3 of all cartons can reach 180° and 135° ,perfectly combing the requirements of auto packaging together.
    ModelZH-800/1050GQ
    Paper MaterialCardboard200-800g, E/F-flute
    Max. Liner speedMax. 280 meter/minute
    Feeding wayAutomatically and continuously feeding
    Way of folding

    Fold 1 and fold 3 are 180°and 135°

    Fold 2 and fold 4 are 180°

    Bottom folded and glued

    Glue MaterialWater-base cold glue
    Electric power7.5kw 380V 50HZ 3P
    Weight3300/3500KG
    Over dimension11500 x (1500/1700) x 1400mm
